Product Description
Input Voltage
| Minimum | Norminal | Maximum |
| 100Vac | 110Vac/240Vac | 264Vac |
Input Frequency
| Minimum | Norminal | Maximum |
| 47Hz | 50Hz/60Hz | 63Hz |
Input Current Limiting
The input current should be less than 3.0A, under minimum AC inpug and full load.
Maximum Energy Consumption in NO-Load
The input power shall be less than 2.0W at 100~240Vac input
Efficiency
The power supply efficiency shall be greater than 85% under rated inpug voltage. It will be measured at the typical load and maximum load.
DC Voltage Regulation
| Rating Output Voltage | No Load Voltage Range | Load Output Voltage Range |
| 67.2V | 64V~70.5V | 45-66V |
| Output Invariable Current | Output Invariable Current Range | Turn Lamp Current |
| 2.0A | 1.8A~2.2A | <500mA |
Line/Load Regulation
| Output | Load Condition | Line Regulation | Load Regulation | Remark | |
| Rate | Min. Load | Max. Load | |||
| +67.2V | 0.1A | 2.0A | ±5% | ±5% | |
Dielectric Strength Testing
| Item | Specification | Remark | |
| Primary to Seondary | 1.5KVac | <5mA/60S | No Arcing |
| Primary to P.G | N/A | N/A | No Broken |
